BODY-WORN CAMERA · SECURITY INTELLIGENCE · 7 MIN READ

VB400 Body-Worn Camera: Take Control of the Situation

Every interaction matters. The VB400 puts an unbiased, encrypted, always-ready witness on your team — seamlessly integrated into your existing operations from day one.

The question facing modern security operations isn't whether to deploy body-worn cameras. It's how to deploy them in a way that fits naturally into existing workflows, provides genuinely usable evidence, and maintains an unbreakable chain of custody from the moment of capture to the moment of review.

The VB400 was designed with exactly those operational realities in mind. It is not a consumer camera repurposed for professional use. It is an end-to-end evidential system — hardware, software, and data management — that integrates with what you already have while elevating every aspect of your video program.

At a Glance

12h

Continuous Recording

1080p

30fps · 120° FOV

AES256

Encryption Standard

IP67

Ingress Protection

810G

MIL-STD Drop Cert.

Always Ready to Record

The VB400's shift-long 12-hour battery life means workers can deploy with confidence that their camera will outlast their rotation. Temperature resistance from -20°C to +50°C covers any climate your team operates in, while IP67 ingress protection handles rain, dust, and whatever else the environment throws at it.

The MIL-STD 810G drop test certification means evidence is protected even when the unexpected happens. Secure mounting options ensure the device stays firmly attached across all uniform types — bulletproof vest, shirt, or jacket — throughout active incidents.

"Pre- and post-record capture ensures the critical seconds before and after a triggering event are never lost — documenting the full context of every interaction."

High-Quality Video Evidence

1080p at 30fps with a 120° horizontal field of view provides comprehensive scene coverage. Low-light performance to 0.2 lux means the camera keeps capturing even in near-dark environments. Dual microphones ensure audio fidelity from all angles.

Recording behaviour is fully configurable through VideoManager. Five buttons can be mapped to different actions per role. Workers get the recording behaviour their job requires — not a one-size-fits-all default.

Feature Overview

Video Quality

1080p at 30fps · 120° FOV · visible in conditions as low as 0.2 lux.

Pre/Post Record

Capture seconds or minutes before and after a triggered event.

Configurable Buttons

5 programmable buttons with customisable LED, vibration & audio feedback.

Automatic Offload

Footage transfers automatically to VideoManager when docked.

Peer-Assisted Recording

Nearby units start recording when one VB400 triggers in a configurable radius.

GPS Tracking

Real-time location via Tactical VideoManager interactive map or API.

Connected to the Bigger Picture

Body-worn cameras are most powerful when they're not isolated. The VB400 connects to your broader security infrastructure through 3rd-party VMS integration — any ONVIF-compatible platform can centralise both body-worn and fixed CCTV streams in a single view.

Holster-aware integration and radio integration (coming soon) mean the VB400 can begin recording automatically when equipment is unholstered or when a MOTOTRBO radio enters an emergency state — reducing cognitive load for responding workers at exactly the moment it matters most.

Connectivity Features

3rd Party VMS Integration — centralise body-worn and fixed camera streams in any ONVIF-compatible platform
Peer-Assisted Recording — surrounding cameras trigger simultaneously in a configurable radius
GPS Location Tracking — Tactical VideoManager map or custom API integration
Radio & Holster Aware Integration (Coming Soon) — automatic recording when radios enter emergency state or equipment is unholstered

Evidential Integrity & Security

The VB400's evidential integrity architecture is designed to be watertight. Footage is encrypted on-device with AES 256 and cannot be accessed by the operator or anyone else until the camera is docked to an authorised VideoManager instance. Data transfers via TLS 1.2 protocol.

Sealed Unit Design

No footage accessible without VideoManager connection. Hardware prevents direct media extraction.

AES 256 Encryption

Footage encrypted at rest and during transit via TLS 1.2. End-to-end protection.

System-Specific Keys

Footage is irretrievable if cameras connect to an unauthorised VideoManager instance.

Footage Verification

SHA256 hashes and certificate-based signing confirm no tampering or editing.

VideoManager: Device & Video Management Made Easy

VideoManager is the operational core of any VB400 deployment. It handles device configuration and user assignment, firmware updates, footage storage and encryption, access control, and integrations with Bluetooth peripherals, third-party VMSs, and the VB Companion app — all from a single interface.

Whether you're deploying five cameras or five hundred, management scales without complexity. Every aspect of a camera's workflow — from assigning it to a user to upgrading its firmware — can be completed directly on VideoManager.

Product Specification

Video Resolution	1080p at 30fps
Field of View	120° horizontal
Low-Light Performance	0.2 lux
Battery Life	12 hours continuous recording
IP Rating	IP67
Drop Certification	MIL-STD 810G
Temperature Range	-20°C to +50°C
Encryption	AES 256 at rest · TLS 1.2 in transit
Footage Verification	SHA256 hashes + certificate-based signing
Backend Software	VideoManager
VMS Compatibility	ONVIF-compatible platforms
